Eaton KTK-R-1/2
$10.00
Eaton Bussmann Series Class CC fuse, KTK-R, fast-acting, dual-element current limiting fuse, 0.5 A, rejection style fuse, interrupting rating of 200kA at 600Vac
Choose Quantity
Product Details
GENERAL SPECIFICATIONS
PRODUCT NAME
Eaton Bussmann series KTK-R fuse
CATALOG NUMBER
KTK-R-1/2
UPC
051712420563
PRODUCT LENGTH/DEPTH
1.5 in
PRODUCT HEIGHT
0.41 in
PRODUCT WIDTH
0.41 in
PRODUCT WEIGHT
0.18 lb
WARRANTY
Not Applicable
COMPLIANCES
RoHS Compliant
CE Marked
CE Marked
CERTIFICATIONS
UL Listed
CSA Certified
CSA Certified
PRODUCT SPECIFICATIONS
TYPE
Current-limiting fast-acting fuse
SPECIAL FEATURES
Rejection style
APPLICATION
Industrial controls panels and machinery, street lighting, general lighting, capacitors and distribution
AMPERAGE RATING
0.5 A
NUMBER OF ELEMENTS
Dual
CLASS
Class CC
INTERRUPT RATING
200 kAIC
FUSE INDICATOR
Non-indicating
CONNECTION
Ferrule end x ferrule end
Ferrule
Ferrule
RESPONSE TIME
See time current curve
MATERIAL
Melamine tube
PACKAGING TYPE
Standard
QUANTITY
10
VOLTAGE RATING
600 V
